Ø 24,5 - 43 mm
Low voltage current transformer
IA100.81
These – over the full operational temperature range - accurate current transformers are suitable for measurement and for revenue metering (billing).
300/5A .. 1600/5A
0,2S
0,1 .. 10 VA
“We are the international manufacturer of measuring, revenue metering and protection transformers for energy generation, energy transport and distribution, energy accounting and energy management. Please contact me for the best solution for you.”
Wim van Turennout, Key Account Manager
+31 (0)6 2039 5494
Order specifications
Ratio | Burden | Class | Article number |
---|---|---|---|
1600/5A | 0,1 – 10 VA | 0.2S | 4M9AK1 |
800/5A | 0,1 – 5 VA | 0.2S | 4M9AK10 |
1000/5A | 0,1 – 5 VA | 0.2S | 4M9AK11 |
1200/5A | 0,1 – 10 VA | 0.2S | 4M9AK12 |
300/5A | 0,1 – 2,5VA | 0.2S | 4M9AK4 |
400/5A | 0,1 – 5 VA | 0.2S | 4M9AK5 |
600/5A | 0,1 – 5 VA | 0.2S | 4M9AK7 |
General Technical Specifications
This product is designed to be safe under the following conditions:
Environmental conditions
Indoor use
-25°C .. +40°C
5% .. 85%, non condensing
IP20
Application conditions
IEC 61869-2
60 x In / 1s
1 x In
0,72/3/-kV
50/60Hz
E
Ø 24,5 - 43 mm. Max rail 80x10 mm
Screw terminals (max. torque 2Nm). Max. cross-sectional area of cable (stranded or solid) 6mm²
