Multiscale Rogowski integrator
Rogowski Integrator
The multiscale Rogowski integrator is a current converter in a compact DIN rail enclosure. The integrator is provided with a push button for an easy scale selection, offering a wide range of applications with a single coil and integrator.
Ratio:100A ... 5000A
100A - 5000A
General technical specifications
This product is designed to be safe under the following conditions:
Environmental conditions
LocationIndoor use
Ambient air temperature-25°C .. +55°C
Storage and transport temperature-25°C .. +70°C
Relative humidity0% .. 80%
Protection degree (secondary terminal)IP20
Application conditions
StandardIEC/EN 61010-1:2010-10; IEC/EN 61326-1:2012
Frequency50/60 Hz
Accuracy class1.5% @ 5% full scale <1% @ full scale
DetailsSelectable scales: 100A, 500A, 1000A, 5000A. Check productsheet for more data.
