GST 200 Aardfout
The GST 200 are cast-resin insulated current transformers for indoor applications. They are suitable for cables or bus-bars. The GST 200 Earth-fault is dedicated to measure phase displacement of a current. Both fixec core transformers and split-core transformers are available.
Primaire stroom:60 A
Secundaire stroom:1 A
ø 140
Algemene technische specificaties
Dit product is veilig te gebruiken onder de volgende omstandigheden:
Omgevingscondities
PlaatsingIndoor use
Omgevingstemperatuur-5°C .. +40°C, other temperatures on request
Opslag- en transporttemperatuur-25°C .. -50°C
Relatieve vochtigheid5% .. 95%, non condensing
HoogteMax. 1000m above NN; at >1000m data required
Beschermingsgraad (secondaire aansluiting)IP20
Toepassings specificaties
IsolatieniveauUp to 200%
NormIEC 61869-2
Kortsluitstroom (lth)20 kA / 1 s
RatedDynanimcCurentLdyn2,5 x Ith
Frequentie 50/60 Hz
IsolatieklasseE
Secundaire stroom1 A
Secundaire aansluitingScrew terminals M5 (max. 2,5 Nm)
Primaire stroom60 A
Nauwkeurigheidsklasse1,2 VA - 1Fs10
Downloads for GST 200 Aardfout
1Downloads available
